A friend of mine challenged me. After telling him how I was able to implement some decent neural network solutions with the help of LLMs, he asked: Could the LLM write a neural network example in Commodore 64 BASIC?
You betcha.
Well, it took a few attempts — there were some syntax issues and some oversimplifications so eventually I had the idea of asking the LLM to just write the example on Python first and then use that as a reference implementation for the C64 version. That went well. Here’s the result:
As this screen shot shows, the program was able to learn the behavior of an XOR gate, the simplest problem that requires a hidden layer of perceptrons, and as such, a precursor to modern “deep learning” solutions.
I was able to run this test on Krisztián Tóth’s (no relation) excellent C64 emulator, which has the distinguishing feature of reliable copy-paste, making it possible to enter long BASIC programs without having to retype them or somehow transfer them to a VIC-1541 floppy image first.
In any case, this is the program that resulted from my little collaboration with the Claude 3.7-sonnet language model:
10 REM NEURAL NETWORK FOR XOR PROBLEM
20 REM BASED ON WORKING PYTHON IMPLEMENTATION
100 REM INITIALIZE VARIABLES
110 DIM X(3,1) : REM INPUT PATTERNS
120 DIM Y(3) : REM EXPECTED OUTPUTS
130 DIM W1(1,1) : REM WEIGHTS: INPUT TO HIDDEN
140 DIM B1(1) : REM BIAS: HIDDEN LAYER
150 DIM W2(1) : REM WEIGHTS: HIDDEN TO OUTPUT
160 DIM H(1) : REM HIDDEN LAYER OUTPUTS
170 DIM D1(1,1) : REM PREVIOUS DELTA FOR W1
180 DIM B2 : REM BIAS: OUTPUT LAYER
190 DIM D2(1) : REM PREVIOUS DELTA FOR W2
200 DIM DB1(1) : REM PREVIOUS DELTA FOR B1
210 DB2 = 0 : REM PREVIOUS DELTA FOR B2
220 LR = 0.5 : REM LEARNING RATE
230 M = 0.9 : REM MOMENTUM
300 REM SETUP TRAINING DATA (XOR PROBLEM)
310 X(0,0)=0 : X(0,1)=0 : Y(0)=0
320 X(1,0)=0 : X(1,1)=1 : Y(1)=1
330 X(2,0)=1 : X(2,1)=0 : Y(2)=1
340 X(3,0)=1 : X(3,1)=1 : Y(3)=0
400 REM INITIALIZE WEIGHTS RANDOMLY
410 FOR I=0 TO 1
420 FOR J=0 TO 1
430 W1(I,J) = RND(1)-0.5
440 NEXT J
450 B1(I) = RND(1)-0.5
460 W2(I) = RND(1)-0.5
470 NEXT I
480 B2 = RND(1)-0.5
510 REM INITIALIZE MOMENTUM TERMS TO ZERO
520 FOR I=0 TO 1
530 FOR J=0 TO 1
540 D1(I,J) = 0
550 NEXT J
560 D2(I) = 0
570 DB1(I) = 0
580 NEXT I
590 DB2 = 0
600 REM TRAINING LOOP
610 PRINT "TRAINING NEURAL NETWORK..."
620 PRINT "EP","ER"
630 FOR E = 1 TO 5000
640 ER = 0
650 FOR P = 0 TO 3
660 GOSUB 1000 : REM FORWARD PASS
670 GOSUB 2000 : REM BACKWARD PASS
680 ER = ER + ABS(O-Y(P))
690 NEXT P
700 IF (E/10) = INT(E/10) THEN PRINT E,ER
710 IF ER < 0.1 THEN E = 5000
720 NEXT E
800 REM TEST NETWORK
810 PRINT "TESTING NETWORK:"
820 FOR P = 0 TO 3
830 GOSUB 1000 : REM FORWARD PASS
840 PRINT X(P,0);X(P,1);"->"; INT(O+0.5);" (";O;")"
850 NEXT P
860 END
1000 REM FORWARD PASS SUBROUTINE
1010 REM CALCULATE HIDDEN LAYER
1020 FOR I = 0 TO 1
1030 S = 0
1040 FOR J = 0 TO 1
1050 S = S + X(P,J) * W1(J,I)
1060 NEXT J
1070 S = S + B1(I)
1080 H(I) = 1/(1+EXP(-S))
1090 NEXT I
1100 REM CALCULATE OUTPUT
1110 S = 0
1120 FOR I = 0 TO 1
1130 S = S + H(I) * W2(I)
1140 NEXT I
1150 S = S + B2
1160 O = 1/(1+EXP(-S))
1170 RETURN
2000 REM BACKWARD PASS SUBROUTINE
2010 REM OUTPUT LAYER ERROR
2020 DO = (Y(P)-O) * O * (1-O)
2030 REM UPDATE OUTPUT WEIGHTS WITH MOMENTUM
2040 FOR I = 0 TO 1
2050 DW = LR * DO * H(I)
2060 W2(I) = W2(I) + DW + M * D2(I)
2070 D2(I) = DW
2080 NEXT I
2090 DW = LR * DO
2100 B2 = B2 + DW + M * DB2
2110 DB2 = DW
2120 REM HIDDEN LAYER ERROR AND WEIGHT UPDATE
2130 FOR I = 0 TO 1
2140 DH = H(I) * (1-H(I)) * DO * W2(I)
2150 FOR J = 0 TO 1
2160 DW = LR * DH * X(P,J)
2170 W1(J,I) = W1(J,I) + DW + M * D1(J,I)
2180 D1(J,I) = DW
2190 NEXT J
2200 DW = LR * DH
2210 B1(I) = B1(I) + DW + M * DB1(I)
2220 DB1(I) = DW
2230 NEXT I
2240 RETURN
The one proverbial fly in the ointment is that it took about two hours for the network to be trained. The Python implementation? It runs to completion in about a second.
